| Collimator type |
X-ray irradiation direction |
detector |
XY platform |
Sample Observation |
|
|
G |
|
bottom-up |
SDD |
fixed or manual |
single camera (fixed or zoom) |
|
B |
|
from top to bottom |
SDD |
fixed |
single camera (fixed or zoom) |
|
P |
|
from top to bottom |
SDD |
Automatic programmability |
single camera (fixed or zoom) |
|
L |
|
from top to bottom |
SDD |
Automatic programmability |
single camera (fixed or zoom) |
Questions to consider when choosing an XRF thickness gauge:
· Sample appearance, size and topography
· The size and topography of the measured part
· Application-specific feasibility assessment, measurable range, calibration method, etc
· Accuracy requirements required for measurement, such as IPC4552, IPC4556, etc
· Measurement reports and export of data
· The test efficiency to be achieved
· Maintenance and safety performance of the instrument
| poly capillary optice type | X-ray irradiation direction |
detector |
XY platform |
Sample Observation |
|
|
O |
|
from top to bottom |
SDD |
Automatic programmability |
Single camera (fixed focus) |
|
M |
|
from top to bottom |
SDD |
Automatic programmability |
Dual camera (fixed focus) |
|
W |
|
from top to bottom |
SDD |
Automatic programmability |
Dual camera (fixed focus) |
|
A |
|
from top to bottom |
SDD |
Automatic programmability |
Dual camera (fixed focus) |
Please contact us for detailed technical specifications. Bowman XRF has 8 series of coating thickness measurement models, and suitable models are selected based on the specific characteristics of the tested samples and application testing needs.
Contact us and inquire about technical selection:+86 400-8383-040,info@applytest.com
